Specifications
- Model Number MB500-KGNN-S00
- Exterior Color Black
- Materials – Outlook Steel, Mesh, Plastic
- Materials – Side Panel Tempered Glass
- Dimensions (L x W x H) 505 x 209 x 499mm (incl. Protrusions), 491 x 209 x 499mm (excl. Protrusions)
- Volume 51L
- Motherboard Support Mini ITX, Micro ATX, ATX, E-ATX*, (*up to 12″ x 10.7″ motherboards, may impact cable management feature)
- Expansion Slots 7
- 5.25″ Drive Bays N/A
- 2.5″ / 3.5″ Drive Bays (Combo) 2
- 2.5″ Drive Bays 4
- I/O Panel 2x USB 3.2 Gen 1 Type-A, 1x 3.5mm Headset Jack (Audio+Mic), 1x Reset/ARGB button
- ARGB Controller ARGB/PWM Hub
- Pre-installed Fans – Top N/A
- Pre-installed Fans – Front 1x 120mm SickleFlow PWM ARGB
- Pre-installed Fans – Rear 1x 120mm MF120 non-LED Fan
- Fan Support – Top 3x 120mm, 2x 140mm
- Fan Support – Front 3x 120mm, 2x 140mm
- Fan Support – Rear 1x 120mm
- Radiator Support – Top 120mm, 140mm, 240mm, 280mm, 360mm, (recommended maximum thickness -55mm)
- Radiator Support – Front 120mm, 140mm, 240mm, 280mm, 360mm
- Radiator Support – Rear 120mm
- Clearance – CPU Cooler 165mm/6.49″
- Clearance – PSU 180mm/7.08″, (295mm / 11.61” with HDD cage removed)
- Clearance – GFX 410mm/16.1″
- Dust Filters Bottom, Front, Top
- Power Supply Support ATX
- Series MasterBox Series
- Size Mid Tower
WHEN LIGHTNING STRIKES
With top-notch gaming support and stealthy, futuristic design, MasterBox 500 really is the best of both worlds. The iconic MasterBox geometric facade features eye-catching, circuit inspired ARGB accents, easily customizable via a dedicated button on the I/O panel to display a stunning array of colors.
The chassis boasts upgraded cooling support, capable of housing a maximum of seven 120mm fans as well as dual 360mm radiators for both air and water cooling versatility. The top panel can be completely removed, allowing for greater access and ease during radiator or fan installations. The pre-installed fans provides powerful, silent cooling while giving users a head start on a fully illuminated build.
ARGB FRONT PANEL
The iconic MasterBox geometric facade features minimalistic, circuit inspired ARGB strips, giving the chassis a stylish and futuristic profile. ARGB lighting can be effortlessly managed via a dedicated button on the I/O panel.
FINEMESH FRONT PANEL
Cooler Master’s FineMesh technology excels in providing maximum airflow, superior dust filtration, and amplifies the ARGB SickleFlow fans installed with a scattered glowing effect.
REMOVABLE TOP PANEL
The top panel is entirely removable for improved access to the components during assembly. Ease of use also facilitates the mounting of cooling solutions such as fans and radiators.
SCREWLESS & TOOL-FREE DESIGN TG SIDE PANEL
The tempered glass side panel is secured with pins for easy removal, facilitating quick access to the internals without the use of tools. An optional screw can be installed to further secure the tempered glass side panel.
VERSATILE COOLING OPTIONS
Support for up to seven 120mm fans and dual 360mm radiators on the top and front panel ensure high compatibility for liquid-cooled systems.
ROOM FOR UPGRADES
Support for up to a 410mm graphics card, a 165mm CPU cooler, and up to a 180mm PSU in length provides room for upgrades to stay ahead of the game.
