Gigabyte M28U 28″ SS IPS Gaming Monitor

Specifications

Panel Size (diagonal)	28″ SS IPS
Display Viewing Area (HxV)	631.928 x 359.78 (mm)
Panel Backlight/ Type	Edge type
Display Surface(non-glare/ glare)	Non-glare
Color Saturation	94% DCI-P3/ 120% sRGB
True Resolution	3840 x 2160 (UHD)
Pixel Pitch	0.16 (H) x 0.16 (V)
Brightness	300 cd/m2 (TYP)
Contrast Ratio	1000:1
Viewing Angle	178°(H)/178°(V)
Display Colors	8 bits
Response Time	1ms GTG / 2ms MPRT
Refresh Rate	144Hz 120Hz for Console Game*
HDR	VESA Display HDR400
Flicker-free	Yes
HBR3	Yes
Connectivity	HDMI 2.1 (support 4K 144Hz 4:4:4 @ DSC enabled or 4K 144Hz 4:2:0) x2 Display port 1.4 (DSC) x1 USB Type-C x1
Earphone Jack	Yes
Speaker	3W x2
Unique Features	OSD Sidekick ** Aim Stabilizer Sync Black Equalizer Dashboard Crosshair Timer Counter Auto-Update KVM 6 axis Color Control Smart OD
USB port(s)	USB 3.0 x3
Power Type	Built-in
AC Input Max	115W
Power Saving Mode	0.5W
Power Off Mode	0.3W
Voltage	AC 100-240V ~ 50/60Hz
Tilt(angle)	-5°~+20°
Swivel(angle)	N/A
Pivot(angle/direction)	N/A
Height Adjustment (mm)	130mm
VESA Wall Mounting(mm)	100*100mm
Kensington lock	Yes
Phys. Dimension with Stand(WxHxD)	636.5*534.2*193.6
Phys. Dimension w/o stand  (WxHxD)	636.5*372.3*63.1
Box Dimension (WxHxD)	890*510*148
Net Weight with stand (Esti.)	6.93 (kg)
Net Weight without stand (Esti.)	5.18 (kg)
Gross Weight (Esti.)	9.7 (kg)
Accessories	Power cable/HDMI cable/DP cable/USB cable/QSG/Warranty card
Note	*HDMI2.1 supports PS5 and Xbox Series X at 4K UHD@120Hz (4:2:0) ** To enable OSD Sidekick, it requires connection between PC and monitor with USB (A-Male to B-Male) cable.

THE LAST MILE FOR YOUR GAMING SYSTEM

As an unseen player, monitor is often being underestimated. The truth is monitors form as a synergistic effect and bring out the best performance of PC components. GIGABYTE gaming monitors offer the ultimate specifications and quality, users can truly enjoy upscale performance without the need for extravagance.



One For All

KVM feature allows you to control multiple devices via one set of keyboard, video and mouse. With our exclusive KVM button, you’ll find switching devices cannot be any easier! Quick like a snap!



1ms GTG Response Time

The SuperSpeed IPS technology reduces the response time to 1ms; meanwhile offering the IPS-grade splendid color!



UHD with 144Hz

High resolution and fast refresh rate, giving you the detailed display quality and fluid gaming experience!



8-bit color, 94% DCI-P3

Fantastic color display and 94% DCI-P3 super wide-gamut color.



HIGH BIT RATE 3

The support of DisplayPort High Bit Rate 3 (HBR3) provides the bandwidth to offer monitor’s fastest refresh rate, full color depth and HDR effect at the same time!

SIMPLE BUT STYLISH

The streamline appearance represents the simplicity of the GIGABYTE gaming series design philosophy, sturdy stand and matte finish built for functional and aesthetic features adding more to the characteristics.



OSD Sidekick

GIGABYTE OSD Sidekick allows you to set the display options with keyboard and mouse, giving you the easiest way to adjust monitor settings.



Counter

The gaming counter will help you calculate the time more easily.



Dashboard

The dashboard reveals your real-time hardware information including CPU voltages, clock speed, temperatures, etc. The best part is that it won’t be blocked by any games.



Black Equalizer

This feature allows you to have more details of the dark side without overexposing the bright side at the same time.



HIGHER LEVEL OF CUSTOMIZED COLOR ADJUSTMENT

With the help of Six Axis Control, it’s able get to control six colors (red, green, blue, cyan, magenta, and yellow) individually. It allows you to more accurately display the color gamut on the monitor.



Auto-Update

Users can effortlessly enjoy the finest gaming experience with features GIGABYTE continues to develop and upgrade while giving extra protection to your monitor.



TECH FEATURES

• Flicker-Free
  Preventing eye strain and fatigue.
• Clear Sound
  Offering the quality sound experience.
• EYESAFE®
  Certified by TÜV Rheinland and Eyesafe® association to meet the standard for color balance and blue light reduction



PERFECT VIEWING ANGLE

GIGABYTE Gaming monitor features an exclusive stand that’s ergonomically designed to offer extensive range of height and tilt adjustments.
